Radiolink TS100 Mini M8N GPS for Mini Pixhawk

Description

The TS100 M8N compact GPS module from RadioLink. Install it on your radio model and monitor its position in real time with updates every 0.1 m/s of flight.

Features

• GPS chip: Radiolink M8N GPS, with U-Blox UBX-M8030 (M8), 72-channel
• Compass: QMC5883L, using the same technology as the HMC5983
• Antenna: 2.5dBi high gain ceramic antenna
• Dual filter: SAWF (Surface Acoustic Wave Filter) from Murata
• Compatible with Pixhawk and Mini-Pix flight controllers with firmware version 3.5.4 or higher

Features

• Model: TS100 mini M8N GPS
• Chip: U-BLOX M8030
• Number of channels: 72
• Supported Standards: GPS, GLONASS, BeiDou, QZSS, SBUS
• Interface: UART
• Positioning accuracy: 50 centimeters
• Measurement speed step: 0.1 m/s
• Maximum altitude: 50000 m
• Maximum velocity: 515 m/s
• Maximum acceleration: 4G
• Maximum update rate: up to 10 Hz
• Sensitivity
  • Tracking and navigation: -167dBm
  • Update: -163dBm
  • Cold Start: -151dBm
  • Hot Start: -159dBm
• Time to first trigger:
  • Cold start: 26 sec
  • Hot start: 1 sec
• Power supply: 5V DC, 50 - 55mA
• Ports: GPS UART interface, geomagnetic I2C interface
• Dimensions: 32 x 30 x 12 mm
• Weight: 20g
